Фильтры микроволны Bandpass

модель

bandpass (GHz)

ILdB)

VSWR

60dB сброс f1 (GHz)

60dBrejection f2 (GHz)

соединитель

размер (mm)

FL2CX2CI67EV09-0112

1.0-2.0

0,5

1,5

     0,793 (45dB)

2,167 (45dB)

SMA-K

278*68*42

FL2CX02CA03CL09-0138

1.92-1.98

1,5

1,5

1,9 (70dB)

2,003 (70dB)

N-K

176*59*38

FL2CX02CA03CL09-0131

1.92-1.98

1

1,5

1,9

2

N-K

149*59*38

FL2CX2WG01CL08-0060

2.01-2.025

1,6

1,5

 1,98 (44dB)

2,05 (35dB)

SMA-K

70*60*36

FL2CX2CI01CL07-0006

2.01-2.025

3

1,3

1,98

2,05

SMA-K

105*21*45

FL2CX02CX01CL11-0255

2.055-2.075

1,5

1,4

2 (38dB)

2,242

SMA-K

62*26*27

FL2CX02CX02CL11-0256

2.232-2.252

1,2

1,5

2,065

2,38

SMA-K

62*26*27

FL2CX02CX10CL11-0236

2.225-2.375

2

1,4

2,155

2,425

SMA-K

170*48*19

FL2CX02CA04CL10-0160

2.4-2.5

0,5

1,2

2,312 (50dB)

2,582 (50dB)

SMA-K

71*42*29

FL2CX03CA08CL10-0202

2.49-2.69

0,6

1,3

2,38 (50dB)

2,786 (50dB)

SMA-K

126*62*30

FL2CX3CI67EV08-0035

2-4

0,7

1,4

1,56

4,38

SMA-K

198*51*34

FL2CX03CI08CL09-0132

3.3-3.6

0,5

1,2

2,844

3,8 (34dB)

N-K

140*30*35

FL2CX3CA17CL10-0154B

3.4-3.8

1,4

1,5

3,351 (70dB)

3,852 (70dB)

SMA-K

196*51*27

FL2WG4WG15CL09-0088

3.6-4.1

0,3

1,2

 2,935 (50dB)

 4,83 (50dB)

SMA-K

117*32*16

FL2WG04WG15DM10-0156

3.625-4.2

0,3

1,4

3,534 (30dB)

4,81 (10dB)

BJ40

198*133*70

FL2WG4WG10CL11-0247

3.7-4.2

0,2

1,4

BJ40

275*99*64

FL2WG4CI12EV09-0097

3.7-4.2

1,2

1,5

3,35 (23dB), 4,25 (23dB)

3,2 (dB 65), 4,4 (dB 65)

BJ84

145*100*70

FL2CX3CI84EV09-0069

2.4-5.6

1

1,4

2,05

6,075

SMA-K

145*26*30

FL2CX3CI84EV09-0073

2.4-6

1

1,4

1,96

6,4

SMA-K

128*26*30

FL2CX05CI41CL10-0200

4-6

2

2

3,68

6,38

SMA-K

180*29*23

FL2CX05CI52CL10-0201

3.75-6.25

2

2

3,4

6,64

Pin 0.38mm

87*20*13

FL2CX5CI01EV07-0004

5.674-5.706

2,2

1,8

5,63

5,75

SMA-K

185*27*27

FL2CX6WG01CL07-0015

5.811-5.847

1,5

1,5

5,747

5,907

SMA-K

142*50*32

FL2CX06CI05CL11-0228

5.841-6.249

0,6

1,5

4,965

7,2

SMA-K

      82*20*20

FL2CX06CI08CL10-0149

6-6.5

1

1,4

5,672

6,782

SMA-K

95*20*17

FL2CX7WG05DM07-0016

6.402-6.72

1

1,5

6,138

6,77

SMA-K

274*60*33

FL2CX7WG04DC07-0018

6.427-6.739

1,3

1,5

6 (46dB)

6,787

SMA-K

132*35*29

UF2CX03CI10CL10-0187

3.1-10.6

1,1

2

1 (48dB)

1,143 (35dB)

SMA-K

115*36*28

FL2CX7WG04ST07-0017

6.81-7.11

0,6

1,2

6,71

7,41 (35dB)

SMA-K

205*42*35

FL2WG8WG08CL07-0020

7.916-8.504

0,3

1,2

7,348

9,252

BJ84

105*46*35

FL2WG8CI09EV07-0013

7.4-8.14

0,7

1,2

6,94

8,7

BJ84

89*46*35

FL2WG8WG08CX09-0074

7.59-8.13

0,4

1,2

7,41 (30dB)

8,54 (30dB)

BJ84

68*69*48

FL2WG8WG01CX09-0070

7.848-7.92

0,3

1,2

7,802 (25dB)

7,986 (25dB)

BJ84

69*67*48

FL2WG8WG05ST09-0093

7.765-8.245

0,6

1,2

7,645 (50dB)

8,391

BJ84

102*46*35

FL2WG8WG08CL07-0001

7.42-8.06

0,6

1,2

6,86 (50dB)

8,88 (50dB)

BJ84

105*43*35

FL2WG8WG08ST07-0007

7.7-8.3

0,9

1,4

7,08

8,49 (50dB)

BJ84

91*46*35

FL2WG08WG06DM09-0128

7.9-8.4

0,9

1,7

7,816

8,464

BJ84

255*58*48

FL2WG08WG06DM10-0193

7.9-8.4

0,3

1,5

7,755

9 (36dB)

BJ84

140*63*48

FL2WG8WG12FS08-0043

7.62-8.67

1

1,2

6,4 (40dB)

8,96

BJ84

39*48*48

FL2CX09CI05CL11-0229

8.775-9.225

0,6

1,5

7,95

10,13

SMA-K

89*18*35

FL2CX10WG05ST09-0072

9.472-10.093

1

1,5

9,347 (50dB)

10,359 (50dB)

SMA-K

44*30*21

FL2CX10CI35CL10-0191

8.35-12.2

0,7

1,5

5,55 (40dB)

14

SMA-K

52*17*12

FL2CX10CA16CL08-0045

9.825-11.125

1,5

1,5

8,325 (50dB)

12,225 (50dB)

SMA-K

62*19*14

FL2CX11CI01CL10-0170

10.75-10.83

2

1,5

10,6 (29dB)

11,98 (25dB)

SMA-K

82*18*16

FL2WG12CI17CL09-0103

10.7-12.75

0,5

1,5

9,59

14 (25dB)

BJ120

75*38*38

FL2WG12WG09CL11-0248

11.8-12.8

0,5

1,5

BJ120

138*38*38

FL2WG14WG05DM08-0052

13.74-14.51

0,6

1,5

13,51

16 (30dB)

BJ120

96*38*38

FL2CX15CI40CL10-0192

12-18

1

1,2

8,2

20,8

SMA-K

68*17*11

FL2CX15CA01CL08-0038

15.364-15.463

3

1,5

15,13 (40dB)

15,67 (40dB)

Pin 0.38mm

35*9*8

FL2PN20CI50CL11-0270

15-25

2

1,5

12,07

28,13

Pin 0.38mm

57*14*12

FL2CX18CI16CL10-0177

16.3-19.05

1,4

1,5

12,95 (50dB)

21,4 (50dB)

SMA-K

28*13*8

FL2CX18CX22CL11-0264

16-20

1,2

1,5

15,05

21,29

2.92-K

94*15*11

FL2CX19CI11CL11-0219

18-20

1,2

1,5

16,7

21,35

SMA-K

68*17*12

FL2CX19CI05CL10-0183

18.24-20.32

2

2

14,72

23,52

SMA-K

50*17*10

FL2CX19CI05CL10-0185

19.07-21.8

2

2

15,38

23,66

Pin 0.38mm

21*13*8

FL2CX19CX19CL11-0283

17.6-21.3

1

1,6

16,17

22,57

Pin 0.38mm

49*16*13

FL2CX20CX15CL11-0262

18-21

1

2

14,95

24,02

SMA-K

52*14*11

FL2CX20CX16CL11-0260

18-21.2

1

1,5

16,35

22,98

SMA-K

70*16*10

FL2WG20WG03CL11-0240

19.7-20.2

0,3

1,2

17,964 (40dB)

22,514 (40dB)

BJ220

32*23*23

FL2CX20CX05CL11-0285

19.975-20.015

1

1,5

19,52 (50dB)

20,48 (50dB)

SMA-K

60*16*12

FL2WG20CA08CL09-0142

19.6-21.2

0,5

1,3

3

18 (27dB)

BJ220

36*23*23

FL2CO20CI08CL09-0120

19.6-21.2

0,9

1,5

18,025 (50dB)

22,42 (50dB)

2.92-K

56*20*12

FL2CX20CI08CL09-0141

19.6-21.2

0,5

1,3

3

18 (27dB)

2.92-K

39×14×10

FL2CX20CI13CL10-0174

19.05-21.8

0,8

1,2

14,39

26,49

Pin 0.38mm

47*14*7

FL2CX21CI05CL09-0140

20.2-21.2

0,5

1,2

2

18 (30dB)

2.92-K

43×14×10

FL2CX21CX14CL11-0257

19.5-22.5

1,1

1,5

17,39

24,67

2.92-K

56*15*10

FL2WG22WG18CL08-0047

19.8-24.2

0,5

1,5

16 (20dB)

28 (20dB)

BJ220

25*23*23

FL2CX22CX38CL11-0294

18-26.5

1

1,5

15,15

29,85

Pin 0.38mm

39*18*12

FL2PN22CI38CL11-0273

18-26.5

1

1,5

15,83

29,87

Pin 0.38mm

40*14*11

FL2CX23CX22CL11-0265

20-25

1,3

1,8

19,07

26,35

2.92-K

83*14*11

FL2CX23CI04CL10-0184

22.8-23.66

2

3

17,45

26 (30dB)

Pin 0.38mm

19*13*9

FL2CX24CX23CL11-0263

21-26.5

1,2

2

20,11

27,78

2.92-K

83*15*11

FL2CX24CX24CL11-0261

20.9-26.6

1,3

2

20,1

28

2.92-K

96*15*11

FL2CX24CX13CL11-0258

22.5-25.5

1

1,5

19,94

29,38

2.92-K

52*15*10

FL2CX25CI08CL11-0220

24-26

1,8

1,5

22,54

27,73

2.92-K

55*13*11

FL2CX25CI28CL10-0182

22-29

1,5

2

17,18

32,36

Pin 0.38mm ВНУТРИ, 2.92-K-KOUT

41*16*10

FL2CX28CX10CL11-0266

26-29

1

1,8

23,27

32,89

2.92-K

54*13*10

FL2CX28CI04CL10-0168

27.5-28.5

1

1,8

25 (32dB)

31 (45dB)

 Pin 0.38mm

18*13*9

FL2CX28CI04CL10-0179

27.5-28.5

1,2

1,5

26,35

30,15

2.92-K

58*13*11

FL2WG29CI16EV11-0214

26.5-31

1,5

1,5

25,275

34,4

BJ320

60*24*20

FL2CX29CX12CL11-0284

27.5-31

1,5

2

26,8

31,9

Pin 0.38mm

78*16*12

FL2CX30CX08CL11-0235

28.5-31.8

0,8

1,5

25,275 (40dB)

36,975 (45dB)

Pin 0.38mm

20*6*6

FL2CX30CX18CL11-0259

27.5~33

1

2

24,79

37,28

2.92-K

57*14*11

FL2WG30WG16NM09-0125

29.14-30.4

1,3

1,6

28,51

31,36

BJ320

53*20*20

FL2CX31CX18CL11-0267

28-33.5

1,2

2

25,37

36,63

2.92-K

58*15*11

FL2CX32CI03CL10-0169

31-32

2

2

28,5 (47dB)

34,84 (50dB)

Pin 0.38mm

40*13*6

FL2CX32CI03CL10-0180

31-32

2,4

2

30,2

33

2.92-K

67*13*11

FL2WG32CI13EV11-0215

30-34

2

1,5

29

37,4

BJ320

61*24*20

FL3PN33CI40CL11-0272

26.5-40

1,1

2

24,5

Pin 0.38mm

50*14*12

FL2CX35CI06CL11-0230

33.6-36.4

1,3

1,5

31,7 (50dB)

39 (33dB)

2.92-K

52*13*10

FL2WG36WG01EV07-0029

35.13-35.83

2

2

32,39 (50dB)

35,87 (50dB)

BJ320

4*19*19

FL2WG38CI11NM11-0217

36-40

1

1,3

34,1

BJ320

49*24*20

FL2WG38WG02DM09-0108

37.67-38.33

1,5

2

37,41

38,61

BJ320

47*21*20

FL2WG40WG00NM10-0203

39.8-39.82

3

1,5

39,3 (50dB)

40 (25dB)

2.92-K

53*13*9

FL2CX40CX3CL11-0274

39.44-40

0,6

1,2

36,63

2.92-K

47*14*11
